JX-1200 Solar Inverter Charger 600W 12V/24V

Solar inverter charger

Modified sine wave solar inverter-charger. Rated Power: 600 W. Peak Power: 1200 VA.

Modified sine wave

Rated Power: 600 W
Peak Power: 1200 VA

Request a quotation Ask on WhatsApp

Need help choosing? Read our buying guide

Customization available

Share your required voltage, sockets and packaging so we can confirm feasibility.

PRODUCT INFORMATION

Specifications & configuration

Confirm the exact voltage and socket configuration for your order.

Specification reference for JX-1200
Product type	Solar inverter charger
Rated Power	600 W
Peak Power	1200 VA
Waveform	Modified sine wave
Battery voltage	12 / 24 V automatic recognition — separate factory-confirmed solar configuration
Solar controller	30 A PWM standard; MPPT configuration on request
Frequency / sockets / accessories	Confirm for your destination and configuration

12V/24V automatic solar system — panel pairing

Battery system: Automatic 12V/24V recognition; no manual voltage-range switching.
Standard controller: 30A PWM. MPPT configuration is available on request.
Factory-verified PWM pairing: One nominal 48V solar panel, or two matching nominal 24V solar panels connected in parallel, for either a 12V or 24V battery system. Parallel connection increases current; it does not add panel voltages.
Maximum total panel nameplate power: 1200W for the standard 30A PWM configuration. The 2000W limit applies only to a configuration actually rated 50A.
Installation: Keep panel voltage, current and total nameplate power within the supplied configuration limits. Follow its wiring instructions. For an MPPT order, use the specifications supplied for that MPPT configuration.

These limits describe the combined rated power printed on the solar panels, not inverter AC output or guaranteed charging power. Send your panel datasheet to match the factory-verified pairing.

View the supplied product / nameplate reference

Reference image for the pictured version. Click to view at full size.

Before you order

Confirm battery compatibility and your equipment load before ordering.

Price, MOQ, sample availability, lead time, warranty and delivery terms are agreed in your quotation.

Documents & customization

Ask for the current datasheet, matching user manual, packing details and any model-specific documents required for your destination.

Describe the voltage, sockets, labels or packaging you need. Customization, minimum quantities and costs require factory confirmation.

How customization works
